drexel® Electric Urban TRIKA98

EV Conversion/Retrofit Service

We are retrofitting small cars into hybrid electric cars.Hybrid vehicle is a revolutionary concept with certified batteries and (battery management system) BMS interface. No major modification is done on the vehicle except for the motor assemblies. Cars that are working on petrol/ diesel are retrofitted in EV car with electric car retrofitting.

Converted conventional vehicle shall run on motor as well as with engine for battery backup power and AC. While engine is on the battery gets partially charged through engine itself which reduces the stopover time of vehicle. Once the battery gets charged level is restored, the vehicle can be shifted to electric mode and engine can be switched off if AC not required. There is no need to stop the vehicle when power is driven from the batteryand vehicle can run up to 4 hours without stopover. Retrofit components are recyclable and can be customized according to the requirements.

The electric components are sealed and fitted as per the norms of the retrofitted electrical vehicle.

Retrofit your fuel powered vehicle into electric
HYBRID RETROFITTING FOR SMALL CARS
Cost
MOTOR

BENEFITS OF RETROFITTING SMALL CARS:

  • The rear wheel assembly is changed and differential plus motor is incorporated which gives stability to vehicle since traction is from rear wheel.
  • Battery statistics is also available by Bluetooth on mobile through BMS.
  • Battery can be charged by existing car alternator/external 230V

Technical Specifications


S. NO Name Technical Specs.
1 Battery Type Lithium as per required 60V, 120A/180A
2 Air cooled motor/Water cooled motor 4 KW/6 KW as per size of car
3 Motor controller Standard
4 Charger 230 V/60 V, 10 Ampere
5 Differential Assembly To Rear wheel Standard
6 Electrical wiring Standard
